Impact resistant chuck

Order no.
Quick-action keyl. ch. Futuro Top 10 mm, 3/8" (636215000)
  • The first impact-proof keyless chuck, with integrated spring-loaded bit clamping mechanism and dual dust protection
  • Keyless for quick tool change
  • Firm grip of clamped tools even under the toughest loads
  • The oil-resistant, hard-wearing rubber bellows system protects the thread and the precision press fit from dust and dirt
  • For clockwise rotating drills only

Clamping width: 1/32 - 3/8 "
Exterior Ø: 1.69 "
Length (closed): 3.03 "
Weight: 0.77 lbs
636215000

Quick-action keyl. ch. Futuro Top 10 mm, 1/2" (636216000)
  • The first impact-proof keyless chuck, with integrated spring-loaded bit clamping mechanism and dual dust protection
  • Keyless for quick tool change
  • Firm grip of clamped tools even under the toughest loads
  • The oil-resistant, hard-wearing rubber bellows system protects the thread and the precision press fit from dust and dirt
  • For clockwise rotating drills only

Clamping width: 1/32 - 3/8 "
Exterior Ø: 1.69 "
Length (closed): 3.03 "
Weight: 0.77 lbs
636216000

Quick-action keyl. ch. Futuro Top 13 mm, 3/8" (636225000)
  • The first impact-proof keyless chuck, with integrated spring-loaded bit clamping mechanism and dual dust protection
  • Keyless for quick tool change
  • Firm grip of clamped tools even under the toughest loads
  • The oil-resistant, hard-wearing rubber bellows system protects the thread and the precision press fit from dust and dirt
  • For clockwise rotating drills only

Clamping width: 1/32 - 1/2 "
Exterior Ø: 1.69 "
Length (closed): 3 1/2 "
Weight: 1.1 lbs
636225000

Quick-action keyl. ch. Futuro Top 13 mm, 1/2" (636226000)
  • The first impact-proof keyless chuck, with integrated spring-loaded bit clamping mechanism and dual dust protection
  • Keyless for quick tool change
  • Firm grip of clamped tools even under the toughest loads
  • The oil-resistant, hard-wearing rubber bellows system protects the thread and the precision press fit from dust and dirt
  • For clockwise rotating drills only

Clamping width: 1/32 - 1/2 "
Exterior Ø: 1.69 "
Length (closed): 3 1/2 "
Weight: 1.1 lbs
636226000

Order no.
Futuro Plus keyless chuck S2 13 mm, 1/2" (636614000)
  • Specially developed for lightweight impact drills
  • Plastic sleeve
  • Double sleeve with radial locking for secure tool clamping
  • Keyless for quick tool change
  • Impact-proof design
  • Drills using locking screw for clockwise and counter-clockwise operating machines
  • With wrench flat for assembly and disassembly

Clamping width: 1.5 - 1/2 mm
Exterior Ø: 1.69 "
Length (closed): 2.85 "
Weight: 0.44 lbs
636614000

Order no.
Futuro Plus keyless chuck S1 13 mm, 1/2" (636617000)
  • Specially developed for lightweight impact drills with spindle stop
  • Plastic sleeve
  • Single sleeve (without supporting ring)
  • Keyless for quick tool change
  • Impact-proof design
  • Drills using locking screw for clockwise and counter-clockwise operating machines
  • With wrench flat for assembly and disassembly

Clamping width: 1.5 - 1/2 mm
Exterior Ø: 1.68 "
Length (closed): 2.85 "
Weight: 0.44 lbs
636617000

Order no.
Keyless chuck Futuro Plus S2M 13 mm, 1/2" (636620000)
  • Specially developed for impact drills
  • Sturdy design with metal sleeve. Version 636619000 with hardened carbide jaws
  • Double sleeve with radial locking for secure tool clamping
  • Keyless for quick tool change
  • Impact-proof design
  • Drills using locking screw for clockwise and counter-clockwise operating machines
  • With wrench flat for assembly and disassembly

Clamping width: 1.5 - 1/2 mm
Exterior Ø: 1.69 "
Length (closed): 2.85 "
Weight: 0.66 lbs
636620000

Order no.
Keyless chuck Futuro Plus S1M 13 mm, 1/2" (636621000)
  • Special design for impact drills with spindle stop
  • Sturdy design with metal sleeve
  • Single sleeve (without supporting ring)
  • Keyless for quick tool change
  • Impact-proof design
  • Drills using locking screw for clockwise and counter-clockwise operating machines
  • With wrench flat for assembly and disassembly

Clamping width: 1.5 - 1/2 mm
Exterior Ø: 1.69 "
Length (closed): 2.85 "
Weight: 0.66 lbs
636621000
