- For drainage and pumping dry of construction pits, cellars and shafts. Also for pumping sewage and waste water in industrial and domestic environments.
- For very coarse dirty water with solid bodies of up to Ø 50 mm
- Double mechanical seal with oil chamber for ideal protection of the pump if the water is very dirty
- Self-cleaning Vortex-impeller to minimise blockages
- Designed for continuous mode with S1 motor operating mode
- Overload protection: protects the motor from overheating
- Float switch for automatic mode
- Suitable for mobile and stationary use thanks to ergonomic handles and stability
- Durable pump housing made of non-corrosive, high-quality stainless steel
Construction and dirty water pump | (220-240 V / 50 Hz)
SP 28-50 S Inox (604114000) Construction and dirty water pump | (220-240 V / 50 Hz)
Order no.: 604114000
Your Delivery Scope
Float switch
- 1470 WRated input power
- 28000 l/h / 7397 gal/hMaximum delivery rate
- 12 m / 39 ftMaximum delivery height
- 7 m / 23 ftMaximum immersion depth
- 50 mm / 2 "Maximum particle size up to
| Rated input power | 1470 W |
| Maximum delivery rate | 28000 l/h / 7397 gal/h |
| Maximum delivery height | 12 m / 39 ft |
| Maximum pressure | 1.2 bar / 17.4 psi |
| Maximum immersion depth | 7 m / 23 ft |
| Discharge port | 2" female thread |
| Pump housing | Stainless steel |
| Protection type IP | IP 68 |
| Maximum particle size up to | 50 mm / 2 " |
| Number of impellers | 1 |
| Dimensions | 203 x 170 x 537 mm // 8 x 6 11/16 x 21 1/8 " |
| Weight | 19.3 kg / 42.5 lbs |
| Cable length | 10 m / 33 ft |
| Float switch |
