Carbide saw blade (60 teeth)
2 Table length extensions
Angle bevel
Material clamp
Tool for saw blade change
Cable winder
Machine stand KSU 251
Mitre saw | (220-240 V / 50 - 60 Hz)
KGSV 72 Xact SYM Set (690972000) Mitre saw | (220-240 V / 50 - 60 Hz)
Order no.: 690972000
Your Delivery Scope
Carbide saw blade (60 teeth)
2 Table length extensions
Angle bevel
- 305 / 215 mm // 12 / 8 15/32 "Maximum cutting width 90°/45°
- 72 / 42 mm // 2 27/32 / 1 21/32 "Maximum cutting depth at 90°/45°
- 1500 WRated input power S1 100%
- 1800 WRated input power S6 20%
- Unique, patented combination of panel saw with sliding function and precise skirting saw with symmetrically adjustable stop system
- Time-saving and accurate sawing of mitres without calculating and measuring thanks to simple angle transfer from bevel to stop system
- Compactly designed sliding function with no space required behind the saw
- Maximum flexibility when sawing thanks to rotating table and inclinable saw head on both sides
- Double line laser for precise display of the cutting line left and right of the saw blade
- Variable speed for an extended range of applications, e.g. for sawing aluminum profiles and plastics
- With saw blade "multi cut" (flat/trapezoidal tooth) for high cutting quality and long service life e.g. in laminate and aluminium profiles
- Compact light-weight with ergonomically designed carry handles, ideal for mobile use
- Effective dust extraction via integrated dust scoop
- Fast and precise setting of common angles using stop points
- Bright LED work light for illumination of the cutting line (mains powered, no batteries required)
- Sliding high rear fence profiles for safe sawing
- Depth guide for easy creation of grooves
- Easy saw blade change by means of spindle lock: No dismantling of the pendulum guard required
| Dimensions | 660 x 540 x 415 mm // 26 x 21 1/4 x 16 11/32 " |
| Maximum cutting width 90°/45° | 305 / 215 mm // 12 / 8 15/32 " |
| Maximum cutting depth at 90°/45° | 72 / 42 mm // 2 27/32 / 1 21/32 " |
| Cutting capacity 90°/90° | 305 x 72 mm // 12 x 2 27/32 " |
| Cutting capacity 45°/45° | 215 x 42 mm // 8 15/32 x 1 21/32 " |
| Turntable setting left/right | 50 / 50 ° |
| Saw blade tilt left/right | 47 / 47 ° |
| Saw blade | 216 mm // 8 1/2 " |
| Rated input power S1 100% | 1500 W |
| Rated input power S6 20% | 1800 W |
| No-load speed | 2200 - 6300 rpm |
| Cutting speed | 25 - 70 m/s // 82 - 229 ft/s |
| Weight | 47.71 kg / 105.2 lbs |
| Sound pressure level | 84 dB(A) |
| Sound power level (LwA) | 97 dB(A) |
| Uncertainty of measurement K | 3 dB(A) |
| Carbide saw blade (60 teeth) |
| 2 Table length extensions |
| Angle bevel |
| Material clamp |
| Tool for saw blade change |
| Cable winder |
| Machine stand KSU 251 |
