Jigsaw blade wood
Hexagonal wrench
Plastic carry case
Jigsaw
STE 100 Quick (601100520) Jigsaw
Order no.: 601100520
Your Delivery Scope
Extraction Nozzles
Protective glass
Chip Guard Plates
- 710 WRated input power
- 100 mm / 4 "Cutting depth wood
- 1000 - 3100 rpmStrokes in idle
- 2 kg / 4.5 lbsWeight (without power cable)
- Extremely slim jigsaw for perfect handling in any application
- Precise and material-matched sawing due to the variable stroke rate, pendulum stroke and low-lying saw blade guidance with spring support
- Metabo Quick for tool-free saw blade change and with automatic ejection
- Selectable chip blowing function ensures free view of cutting line
- Vario-Tacho-Constamatic (VTC)-Full Wave Electronics for work with materials requiring customised stroke rates, which remain almost constant under load
- Extraction possibility by means of connecting an all-purpose vacuum cleaner
- Non-detachable protective glass that can be pushed down for effective extraction and for protection against flying chips
- Precision guide rail and guiding device available as accessory
| Rated input power | 710 W |
| Output power | 470 W |
| Cutting depth wood | 100 mm / 4 " |
| Cutting depth NF metal | 25 mm / 1 " |
| Cutting depth sheet steel | 10 mm / 3/8 " |
| Swivel range from / to: | - 45 / + 45 ° |
| Pendulum stroke levels | 4 |
| Strokes in idle | 1000 - 3100 rpm |
| Saw blade stroke | 22 mm / 7/8 " |
| Weight (without power cable) | 2 kg / 4.5 lbs |
| Cable length | 4 m / 13 ft |
| Sawing wood | 13 m/s² |
| Uncertainty of measurement K | 1.5 m/s² |
| Sawing metal | 13.7 m/s² |
| Uncertainty of measurement K | 1.5 m/s² |
| Sound pressure level | 86 dB(A) |
| Sound power level (LwA) | 97 dB(A) |
| Uncertainty of measurement K | 3 dB(A) |
| Extraction Nozzles |
| Protective glass |
| Chip Guard Plates |
| Jigsaw blade wood |
| Hexagonal wrench |
| Plastic carry case |
