Keyless chuck
Side handle
Belt hook and bit case
2 LiPOWER battery packs (18 V/5.2 Ah)
Charger ASC 55 "AIR COOLED"
metaBOX 145 L
Cordless hammer drill
SB 18 LTX BL I (602360520) Cordless hammer drill
Order no.: 602360520
Your Delivery Scope
Keyless chuck
Side handle
Belt hook and bit case
- 18 VBattery voltage
- 65 Nm / 575 ft. lbsMaximum torque, soft
- 130 Nm / 1151 ft. lbsMaximum torque, hard
- 16 mm / 5/8 "Drill-Ø masonry
- 13 mm / 1/2 "Drill Ø steel
- 68 mm / 2.68 "Drill-Ø soft wood
- 0 - 550 / 0 - 2000 rpmNo-load speed
- A true power house: safe, brushless cordless hammer drill with maximum power for the toughest applications
- Hammer drill function for drilling in masonry
- Selectable "impuls" mode for removal of stubborn screws and for spot-drilling on smooth surfaces
- Robust, durable gear housing made from aluminium die-cast
- Powerful Brushless motor for greatest efficiency and long battery pack runtime
- Precision Stop: electronic torque control with increased precision for precise, delicate working
- Overload protection: protects the motor from overheating
- Euro collar (Ø 43 mm) for versatile use
- Electronic safety shutdown: no kickback if the drill bit stops unexpectedly - for high user safety
- Integrated LED work light with afterglow function for optimal brightness in the work area
- With handy belt hook and bit case which can be fixed either on the right or left side
- Many brands, one battery pack system: This product can be combined with all 18V battery packs and chargers of the CAS brands: www.cordless-alliance-systems.com
| Type of battery pack | LiPOWER |
| Battery voltage | 18 V |
| Battery pack capacity | 2 x 5.2 Ah |
| Maximum torque, soft | 65 Nm / 575 ft. lbs |
| Pulse torque | 65 Nm / 575 in-lbs |
| Maximum torque, hard | 130 Nm / 1151 ft. lbs |
| Adjustable torque | 1 - 20 Nm // 9 - 177 in-lbs |
| Drill-Ø masonry | 16 mm / 5/8 " |
| Drill Ø steel | 13 mm / 1/2 " |
| Drill-Ø soft wood | 68 mm / 2.68 " |
| No-load speed | 0 - 550 / 0 - 2000 rpm |
| Maximum impact rate | 38000 bpm |
| Chuck capacity | 1.5 - 13 mm // 1/16 - 1/2 " |
| Collar diameter | 43 mm / 1 11/16 " |
| Weight without battery pack | 1.8 kg / 4 lbs |
| Weight with battery pack | 2.5 kg / 5.5 lbs |
| Drilling in metal | 2.6 m/s² |
| Uncertainty of measurement K | 1.5 m/s² |
| Impact drilling concrete | 16.5 m/s² |
| Uncertainty of measurement K | 1.7 m/s² |
| Sound pressure level | 92 dB(A) |
| Sound power level (LwA) | 103 dB(A) |
| Uncertainty of measurement K | 3 dB(A) |
| Keyless chuck |
| Side handle |
| Belt hook and bit case |
| 2 LiPOWER battery packs (18 V/5.2 Ah) |
| Charger ASC 55 "AIR COOLED" |
| metaBOX 145 L |
