Carbide circular saw blade (18 teeth)
Parallel guide
Hexagonal wrench
Cross cutting rail KFS 44 (44 cm)
metaBOX 340
without battery pack, without charger
Cordless circular saw
KS 18 LTX 66 BL Set (691194000) Cordless circular saw
Order no.: 691194000
Your Delivery Scope
Carbide circular saw blade (18 teeth)
Parallel guide
Hexagonal wrench
- 18 VBattery voltage
- 66 mm / 2 19/32 "Maximum cutting depth at 90°
- 165 x 20 mm // 6 1/2 x 5/8 "Saw blade Ø x bore
- 4800 rpmNo-load speed
- Powerful, light, cordless circular saw for universal use on construction sites
- Aluminium base plate can be directly used on guide rails from Metabo and Mafell, Bosch, Festool, Makita, HiKOKI, Hilti and other manufacturers
- Fast, precise cross cuts thanks to easy coupling with a Metabo KFS cross cutting rail
- Automatic switching on/off of the connected vacuum cleaner thanks to CordlessControl. (available as accessory)
- Sawdust ejection nozzle for any working position can be rotated and locked individually
- Integrated LED work light for optimum illumination of the cutting line
- 0° position re-adjustable for highest cutting precision
- Clearly visible cutting indicator for precise sawing after initial cut
- Robust and durable thanks to aluminium die-cast saw housing
- Handle with non-slip soft-grip surface for safe guidance
- Extraction possibility by means of connecting an all-purpose vacuum cleaner
- Many brands, one battery pack system: This product can be combined with all 18V battery packs and chargers of the CAS brands: www.cordless-alliance-systems.com
| Battery voltage | 18 V |
| Swivel range from / to: | 0 / + 46 ° |
| Adjustable cutting depth | 0 - 66 mm // 0 - 2 19/32 " |
| Maximum cutting depth at 90° | 66 mm / 2 19/32 " |
| Maximum cutting depth at 45° | 43 mm / 1 11/16 " |
| Max. cutting depth with guide rail | 61 mm / 2 13/32 " |
| Saw blade Ø x bore | 165 x 20 mm // 6 1/2 x 5/8 " |
| No-load speed | 4800 rpm |
| Max. cutting speed | 43 m/s / 141 ft/s |
| Weight without battery pack | 3.5 kg / 7.7 lbs |
| Weight with battery pack | 4.5 kg / 9.9 lbs |
| Sawing chipboards | 2.5 m/s² |
| Uncertainty of measurement K | 1.5 m/s² |
| Sound pressure level | 87 dB(A) |
| Sound power level (LwA) | 98 dB(A) |
| Uncertainty of measurement K | 3 dB(A) |
| Carbide circular saw blade (18 teeth) |
| Parallel guide |
| Hexagonal wrench |
| Cross cutting rail KFS 44 (44 cm) |
| metaBOX 340 |
| without battery pack, without charger |
